| Sensor | High Definition Color CMOS Sensor |
| Display Resolution | 2560×1440 (4.0 Megapixels) |
| Min. Illumination | 0 Lux (with IR Illuminator) |
| Lens Type | Glass lens |
| Focal Length | f:4mm |
| Aperture | F=2.1 |
| Diagonal Angle of View | 78° |
| Image Compression | H.264 |
| Image Frame Rate | 25fps, downward adjustable |
| Resolution | 4.0M (2560×1440),3.0M (2304×1296) |
| 1080P (1920×1080), 720P (1280×720), VGA (640×480), QVGA (320×240) |
| Stream | Dual stream |
| Image Adjustment | The hue, brightness, contrast, saturation and sharpness are adjustable |
| Flip Image | Flip and mirror |
| Infrared Mode | Automatic or manual |
| Night Visibility | With 30pcs IR-LED, IR range up to 20 meters |
| Input/Output | External RCA interface for two-way audio |
| Audio Compression | PCM/G.726 |
| Ethernet | One 10/100Mbps RJ45 port |
| Remote Access | P2P DDNS |
| Network Protocol | IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS, UPnP, RTSP, ONVIF |
| Operating System | Microsoft Windows 2000/XP, Vista, 7, 8; Mac OS |
| Browser | Microsoft IE8 and above versions or other compatible browsers; Apple Safari |
| Motion Detection | Alarm via email, upload alarm snapshot to FTP |
| Privacy Block | Set privacy area manually |
| User Account | Three-level user role |
| Firewall | Supports IP filtering |
| Reset | Reset button is available |
| Power Supply | DC 12V/1.0A |
| POE Standard | 802.3af |
| Power Consumption | 5W (Max.) |
| Dimensions (L×W×H) | 98×65×62mm (3.86"e;×2.56"e;×2.44"e;) |
| Net Weight | 255g |
| Waterproof | IP66 |
| Operating Temperature | -20°C~60°C (-4°F~140°F) |
| Operating Humidity | 10%~80% (non-condensing) |
| Storage Temperature | -20°C~60°C (-4°F~140°F) |
| Storage Humidity | 0%~90% (non-condensing) |
| Certification | FCC, IC, CE, WEEE, IP66 |
| Warranty | Limited 2-year warranty |
