| Video Input |
IP Video Input |
4 Channels HD IP camera input |
| Video Output |
HD Output |
1×HD OUT |
| VGA Output |
1×VGA |
| Display Resolution |
1280x720/60Hz, 1280x1024/60Hz, 1280x720/50Hz, 1280x1024/50Hz |
| Recording |
Recording Resolution |
720P per channel ( [email protected] ) |
| Record Mode |
Manual / Time Scheduled / Motion Detect |
| Compression Format |
H.264 |
| Playback |
Synchronous Playback |
4 channel 720P synchronous video playback |
| Playback Mode |
Fast forward / Fast backward / Frame forward / Slow Play |
| Network |
Ethernet |
One 10/100Mbps RJ45 port |
| Wireless Standard |
IEEE802.11b/g/n |
| Wireless Security |
WEP, WPA, WPA2 |
| Network Protocol |
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS, RTSP, UPnP, ONVIF |
| HDD |
HDD |
1TB security grade hard drive (pre-installed) |
| Capacity |
Up to 4TB |
| External Interface |
Network Interface |
1× 10/100 Mbps RJ45 port |
| USB Interface |
1× USB2.0 interface for mouse and external storage |
| Button |
1× Power on/off button, 1× Reset button |
| Software |
Computer Operating System |
Microsoft Windows XP, 7, 8, 8.1, 10, Mac OS |
| Internet Viewing |
Microsoft IE8 and above versions, Safari |
| Smart phone |
iOS, Android, 3G/4G Smartphones |
| Language |
Language |
14 languages (Chinese, English, French, Hungarian, Czech, Dutch, Greek, Russian, Polish, Spanish, Portuguese, Italian, German, Finland) |
Physical and
Environmental |
Power Supply |
DC 12V/2A |
| Dimensions (LxWxH) |
234x234x52mm (9.25''x9.25''x2.04'') |
| Net Weight (g) |
660g |
| Operating Temperature |
-10°C~55°C (-4°F~131°F) |
| Operating Humidity |
20%~85% (non-condensing) |
| Storage Temperature |
-20°C~60°C (-4°F~140°F) |
| Storage Humidity |
0%~90% (non-condensing) |
| |
|
|
| Camera |
Model |
FI9800W |
| Image Sensor |
Sensor Type |
1/4" CMOS |
| Video Quality |
720P (1280x720) |
| Backlight Compensation |
√ |
| Lens |
Lens Type |
f:4mm, F:2.0 |
| IR Range |
65 feet (20 meters) |
| Infrared Mode |
Automatic or manual |
| View Angle |
62° |
| Network |
Ethernet |
One 10/100Mbps RJ45 port |
| Wireless Standard |
IEEE802.11b/g/n |
| Data Rate |
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.). |
| Wireless Security |
WEP, WPA, WPA2 |
| Network Protocol |
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS, RTSP, ONVIF |
| Software Features |
Video Format |
H.264 |
| Multi-Stream |
Dual streams |
| Motion Detection |
√ |
| Day/Night |
√ |
Physical and
Environmental |
Waterproof |
IP66 |
| Net Weight |
360g |
| Power |
DC12V |
| Power Consumption |
<5W |
| Dimensions (LxWxH) |
97(L)x67 (W)x64 (H) |
| Certification |
FCC, IC, CE, IP66 |
| Operating Temperature |
-10°C~60°C (14°F~140°F) |
| Operating Humidity |
10%~80% (non-condensing) |
| Storage Temperature |
-20°C~60°C (-4°F~140°F) |
| Storage Humidity |
0%~90% (non-condensing) |
