| Video Input |
IP Video Input |
8 Channels HD IP camera input |
| Video Output |
HD Output |
1×HD OUT |
| VGA Output |
1×VGA |
| Display Resolution |
1920×1080/60Hz, 1280×720 /60Hz, 1440×900/60Hz, 1024×768/60Hz |
| Recording |
Recording Resolution |
1080P per channel ( 8ch@1080P ) |
| Record Mode |
Manual / Time Scheduled / Motion Detect |
| Compression Format |
H.264 |
| Playback |
Synchronous Playback |
4 channel 1080P synchronous video playback |
| Playback Mode |
Fast forward / Fast backward / Frame forward / Slow Play |
| HDD |
Capacity |
Up to 4TB |
| External Interface |
Network Interface |
1× 10/100/1000 Mbps RJ45 port |
| USB Interface |
1× USB2.0 / 1× USB3.0 interface for mouse and external storage |
| Button |
1× Power on/off button,1× Reset button |
| Software |
Computer Operating System |
Microsoft Windows XP, 7, 8, 8.1, Mac OS |
| Internet Viewing |
Microsoft IE8 and above version,Safari |
| Smart phone |
iOS, Android, 3G/4G Smartphones |
| Language |
Language |
13 languages （Chinese、English、French、Hungarian、Czech、Dutch、Greek、Russian、Polish、Spanish、Portuguese、Italian、German） |
| Physical and Environmental |
Power Supply |
DC 48V & 1.87A |
| Dimension(LxWxH) |
234mm*234mm*52mm |
| Net Weight (g) |
1200g |
| Operating Temperature |
-10°C ~ 55°C (-4°F ~ 131°F) |
| Operating Humidity |
20% ~ 85% non-condensing |
| Storage Temperature |
-20°C ~ 60°C (-4°F ~ 140°F) |
| Storage Humidity |
0% ~ 90% non-condensing |
