| ITEMS |
FI9926P |
| Image Sensor |
Sensor |
High Definition Color CMOS Sensor |
| Display Resolution |
1920*1080P(2.0Megapixel) |
| Min. Illumination |
0 Lux (With IR Illuminator) |
| Lens |
Lens Type |
Glass Lens |
| focal length |
f:2.8~12mm |
| Aperture |
F1.4 |
| Angle of View |
Horizontal:36°~101°
Diagonal :41°~117° |
| Video |
Image Compression |
H.264 |
| Image Frame Rate |
30fps maxmium, downward adjustable |
| Resolution |
(2.0Megapixels)1920 x 1080, 720P(1280 x 720), VGA(640 x 480), VGA(640 x 360), QVGA(320 x 240), QVGA(320 x 180) |
| Stream |
dual stream |
| Image adjustment |
The hue, brightness, contrast, saturation, sharpness are adjustable |
| Flip image |
flip and mirror |
| Infrared mode |
Automatic or manual |
| Pan/Tilt Angle |
Horizontal:300° & Vertical: 100° |
| Night visibility |
20pcs IR-LEDs, night vision range up to 10 metres |
| Audio |
Input/Output |
Supports two-way audio
Built-in Mic & Speaker |
| Audio Compression |
PCM/G.726 |
| Network |
Ethernet |
One 10/100Mbps RJ45 port |
| Wireless network |
Support 2.4G & 5G dual-band wireless network |
| Wireless Standard |
2.4G：IEEE802.11b/g/n
5G：IEEE802.11a/n/ac |
| Data Rate |
2.4GHz：
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
5GHz：
IEEE802.11a: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.);
IEEE802.11ac: 433Mbps(Max.). |
| Wireless Security |
WPA, WPA2 |
| WPS |
Supports WPS one button push wireless connection |
| Network Protocol |
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、RTSP、WPS |
| System Requirements |
Operating System |
Microsoft Windows Vista, 7, 8,10;
Mac OS
iOS, Android |
| Browser |
Microsoft IE7 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari. |
| Other Features |
Motion Detection |
Alarm via E-Mail, upload alarm snapshot to FTP |
| Privacy Zone |
Set privacy zone manually |
| User Accounts |
Three levels user role |
| Firewall |
Supports IP Filtering |
| Reset |
Reset button is available |
| Intelligent Assistant |
Suppports Google Assistant, Alexa |
| Power |
Power Supply |
DC 5V/2.0A |
| Power Consumption |
6 Watts (Max.) |
| Physical |
Dimension(LxWxH) |
115.8(L)*103.2(W)*118.6(H) mm |
| Gross Weight |
790g |
| Net Weight |
380g |
| Environment |
Operating Temperature |
-10°C ~ 50° (14°F ~ 122°F) |
| Operating Humidity |
20% ~ 85% non-condensing |
| Storage Temperature |
-20°C ~ 60° (-4°F ~ 140°F) |
| Storage Humidity |
0% ~ 90% non-condensing |
| Certification |
CE, FCC, RoHS、WEEE |
