TI TITAN chipset and TI voice engine
132x64 graphic LCD
3 VoIP accounts, Broadsoft /Avaya/Asterisk validated
HD Voice: HD Codec, HD Handset, HD Speaker
32 keys including 4 soft keys
SMS, Voicemail, Intercom
Localized language, XML phonebook
FTP/TFTP/HTTP, PnP Auto-provision
SRTP/HTTPS/TLS, VLAN, QoS
PoE, Headset, Wall-Mounted
Video
Phone Features
3 VoIP accounts, hotline, emergency call
Call waiting, call transfer, call forward
Hold, mute, flash, auto-answer, redial
3-way conference, DND, speed dial
Phonebook (each record with 3 phone
numbers, 300 entries), black list
XML Phonebook search/import/export
Lists of missed, received, dialed and
forwarded calls (100 entries in all)
Volume adjustment, ring tone selection
Tone scheme, System log
Multi-language (more than 20)
IP PBX System Integration
Dial plan, dial-now
SMS, Voicemail, MWI
Intercom
Call park, call pickup
Distinctive ringtone
Codecs and Voice Features
Wideband codec: G.722
Narrowband codec: G.711, G.723.1, G.726, G.729AB
VAD, CNG, AEC, PLC, AJB, AGC
Full-duplex speakerphone with AEC
Network Features
SIP v1 (RFC2543), v2 (RFC3261)
NAT Traversal: STUN mode
DTMF: In-Band, RFC2833, SIP Info
Proxy mode and peer-to-peer SIP link mode
IP Assignment: Static/DHCP/PPPoE
TFTP/DHCP/PPPoE client
HTTP/HTTPS server
DNS client
NAT/DHCP server
Management
FTP/TFTP/HTTP/PnP auto-provision
Configuration: browser/phone/auto-provision
Direct IP call without SIP proxy
Dial number via SIP server
Dial URL via SIP server
Security
HTTPS (server/client)
SRTP (RFC3711)
Transport Layer Security (TLS)
VLAN (802.1 pq), QoS
Digest authentication using MD5/MD5-sess
Secure configuration file via AES encryption
Phone lock for personal privacy protection
Admin/user configuration mode
Physical Features
TI TITAN chipset
132x64 graphic LCD
32 keys including 4 soft keys
5 LEDs: 1xpower, 3xline, 1xmessage
1xRJ9 handset port
1xRJ9 headset port
2xRJ45 10/100M Ethernet ports
Wall-mounted
Power adapter (optional):
AC 100~240V input and DC 5V/1.2A Output
Power over Ethernet (IEEE 802.3af)
Power consumption (PSU): 1.4-2.0W
Power consumption (PoE): 2.1-2.9W
Dimension: (W*D*H*T):
209mm*188mm*150mm*41mm
Operating humidity: 10~95%
Operating temperature: -10~50°C
